FuriBee F3 32-bit Brushed Flight Controller

FuriBee F3 32-bit Brushed Flight Controller
Seller: GearBest,


Main Features:
- Based on F3 flight controller, FuriBee F3 flight controller features some improvements
- Its high-performance STM32F303CCT6 32-bit processor with 256KB flash brings you better flight experience
- The FrSky receiver is characterized by 200m long receive distance, data return, and stable signals
- Caters different groups by supporting 1S 4.2V input, onboard 5V and 3.3V output
- It can be connected to video transmitters and other receivers
- Excellent electric circuits. There is always 1A output current at 5V, which ensures the high performance of both the flight controller and its peripherals
- Supports signal input of SBUS, DSM satellite, PPM receivers, offering you more options
- Micro USB connector for programming
- Suitable for mini RC quadcopters like Blade Inductrix, E010, JJRC H36, FuriBee F36 and so on

Specifications:
- STM32F303CCT6 32-bit processor with 256KB flash
- MPU6050 gyro / accelerometer
- High quality, gold plated PCB
- Integrated FrSky 8CH receiver, serial port output
- With the built-in DC-DC boost circuit, it can be powered by other devices via IIC or UART port
- Motor drive frequency: 2K ( it can be set by users, 32K at maximum )
- Parameters can be configured in CleanFlight
- Dimension: 27.5 x 27.5mm
- Weight: 2.7g

Note:
The protective frame and the motors in the picture are not included.

Specification

General

Brand: FuriBee
Type: Flight Controller

Dimension and Weight

Package weight: 0.020 kg
Product size (L x W x H): 2.75 x 2.75 x 0.10 cm / 1.08 x 1.08 x 0.04 inches
Package size (L x W x H): 4.00 x 4.00 x 1.00 cm / 1.57 x 1.57 x 0.39 inches

Package Contents

Package Contents: 1 x F3 Flight Controller, 1 x Power Cable, 4 x Shock Absorber, 4 x Screw
