FullSpeed FSD Leader 3 130mm FPV Racing Drone F4 OSD 28A BLHeli_S Dshot600 48CH 600mW Caddx Micro F1 PNP
Description:
Brand name: FullSpeed
Item name: Leader 3 FPV Racing Drone
Weelbase: 130mm
Net weight: 87g
Thickness of bottom plate: 3mm
Thickness of side plate: 2mm
Flight controller: FSD F411 built-in OSD
ESC: FSD 28A BLHeli_S 2-4S 4 in 1 ESC Dshot600
Motor: 1106 4500KV
Propeller: HQ3x3x3
Camera: Caddx Micro F1
VTX: FSD TX600 25/100/200/400/600 switchable VTX
FullSpeed FSD F411 flight controller:
Size: 27.5mm * 27.5mm * 5mm
Mounting hole: 20mm * 20mm
MCU: STM32 F411
Built-in Betaflight OSD
Firmware: FULLSPEEDF411 Betaflight
BEC: 5V/3A
FullSpeed FSD 28A BLHeli_S 4 in 1 ESC:
Size: 27mm * 27mm * 5mm
Mounting hole: 20mm * 20mm
Firmware: BLHELI_S
Input voltage: 2-4S
Continuous current: 28A
BEC ouput: NO
FullSpeed FSD TX600 25mW-600mW VTX FPV Transmitter:
Output power: PIT/25mW/100mW/200mW/400mW/600mW switchable
Control mode: BFOSD control(RX)/button
Video system: NTSC/PAL
Antenna: IPEX
BAT: 5V Recommended
Frequency: 5.8GHz 6 bands 48 channels, with Raceband: 5362-5945 MHZ
(TX600's factory set up is on lock mode (5733-5866MHZ unlock). Please follow your local laws and regulations if you need to unlock the frequency.)
Size: 26*26mm(L*W), Hole:20*20mm
Weight: 2.3g
Package included:
1 x Leader 3 frame kit
1 x FSD428 F411 28A flight tower
4 x 1106 4500KV brushless motor
2 x HQ 3x3x3 propeller (CW)
2 x HQ 3x3x3 propeller (CCW)
1 x Caddx micro F1 camera
1 x FSD TX600 25mW-600mW VTX
