FSFLY 2.4G 7CH F701 Receiver Supported JR Spektrum DSM-X DSM2 Transmitter
Description:
The F701 receiver is a great solution for all model aircraft requiring full range up to 7 channels. This receiver is more powerful than AR7000 Receiver, This dual path redundancy, plus the fact each of the two receivers is located in a slightly different location, exposes each to a different RF environment and creates a bulletproof RF link in all conditions.
Brand Name: FSFLY
Item Name: F701
Specification:
Brand Name: FSFLY
Item Name: F701
Band: 2.4GHz
Channel: 7
Operating Voltage: 4.8V-8.4V
Operating Current: 45mA
Range: 1500M+/full
Response Speed: 22ms
Dimension: 48 x 25 x 14mm
Weight: 15g
Resolution: 2048
Features:
Adopt DSSS - 2 and DSSS - X technology
Special high gain antenna,with high gain amplifier,stable and long distance
Support PPM channel
Extra Satellite is not needed,more convenient.
Compatible with Spektrum and JR transmitter,suitable for RC helicopter/quadcopter/airplane
How to match the code:
a: Plug the code bar to BIND CON on the receiver
b: Electricity to receiver
c: Hold down the code match switch on
d: Receiver lights flash to normally on, means the code match success
e: Unplug the code bar
Package Included:
1x F701 receiver
1x Bind plug
