Frsky XMF3E Built-in F3EVO Flight Controller & 16CH SBUS XM Receiver Compatible Taranis X9D/Q X7/XJT
Specifications: Instruction Manual
Brand Name: Frsky
Item Name: XMF3E
Dimension: 29x29x6mm (L x W x H)
Weight: 3.4g
Hardware: STM32F303 CPU (72Mhz inc FPU)
MPU9250 (accelerometer/gyro/compass)
CC2510 CPU for XM receiver
Channels: 16CH (8CH is RSSI) by SBUS to UART2 RX of F3EVO
Operating voltage/current: 4.2V@75mA
Compatibility: Frsky Taranis X9D/X9E/Q X7/Horus X12S/XJT in D16 mode
Firmware Upgradeable
Features:
-Built-in F3EVO and XM receiver module
-Features the latest Accelerometer, Gyro and Compass and Baro sensor technology.
-XM receiver is a one-way receiver (no telemetry), it will receive the commands of Remote Control and send to F3EVO by SBUS (8CH is RSSI) to UART2 RX of F3EVO
Software:
The F3EVO runs the open-source Cleanflight/Betaflight flight control (FC) software and firmware upgradeable (SPRACINGF3EVO), the factory firmware is betaflight_3.0.0_SPRACINGF3EVO.
The XM receiver runs the software which was developed by Frsky and firmware upgradeable.
For XM receiver Status
Blue LED for F3EVO Status
Package Included:
1 x Frsky XMF3E
