Specifications:
Brand Name: FrSky
Item Name: FrSky VD5M Receiver
Dimension: 21 x 16 x 5.8mm
Weight: 2.0g
Number of Channels: 5
Operating Voltage Range: 3.0V-7.2V
Operating Current: 20mA
Operating Range: >300M
Connector Specification: 1.25mm pitch
Features:
Super small and light, designed for park flyers and indoor aircrafts;
Compatible with all FrSky modules (V8 mode & D mode), receive only (VD5M can talk with module of either mode, but it does not send any telemetry information back to the transmitter
Compatibility:
Channels Connected by Binding Cable Mode of VD5M FrSky Compatible Modules CH1 & CH5
V8 Mode
(Non-telemetry)
V8FT, V8JT, V8HTDFT, DJT, DHT, DHT-U in V8 Mode
(Switch 1 OFF, Switch 2 ON)
CH2 & CH5 D Mode (Telemetry)DFT, DJT, DHT, DHT-U in D Mode
(Switch 1 OFF, Switch 2 OFF)
Note: Make sure corresponding channels are connected by provided binding cable when working with the transmitter module.
Package Included:
1 x FrSky VD5M Receiver
