FrSky S-FHSS 8CH Delta-8 Receiver For Futaba T6J T8J 4PL 14SG Transmitter
Description:
Brand Name: Frsky
Item Name: Delta-8 receiver
Frequency: 2.4G
Channel: 8
Dimension: 36 x 17.5 x 8mm
Weight: 3.5g / 2.7g (net)
Operating Current: 30mA
Operating Voltage: 3.0~16.0V (HV version)
Typical Range: >1.5km (Full Range)
Compatible Transmitter: Hitec A9,Futaba T6J,T8J,4PL,14SG
Compatible System: Frsky -- Taranis transmitter,DFT/DJT/DHT/DHT-U one-way mode and bidirectional mode
Futaba -- S-FHSS/FHSS
Hitec -- A-FHSS
FrSky modules How to put V8R4-II into binding mode respectively V8FT, V8JT, V8HT V8_Mode (Non-telemetry)
Connect battery to V8R4-II while holding the F/S button on V8R4-II DFT, DJT, DHT, DHT-U in V8_Mode
(Switch 1 OFF and Switch 2 ON) DFT, DJT, DHT, DHT-U in D_Mode
(Switch 1 OFF and Switch 2 OFF) D_Mode (Telemetry)
Connect Ch1 & Ch2 signal pins of V8R4-II by provided jumper and then
connect battery to V8R4-II directly (no need to hold the F/S button on V8R4-II)
Package Included:
1x Receiver
