The new RX8R Pro receiver is an updated version with higher precision and even lower latency. It supports the redundancy function, which means you can connect a second receiver to act as a back up in the case one fails. In addition, the Rx8R Pro has a decreased effect of interference from the ignition process. All these features make this receiver ideal for any gas or nitro model.
For internal combustion models, it's key to know the status of your engine while in flight. The FrSky Gas Suite is a multifunctional unit in 1 neat little package. This neat little package can monitor the operating temperature, RPM, and fuel flow velocity of your engine. In addition, the Gas Suite allows you to control the ignition system manually, allowing the user full control of the engine.
These two units combined make a perfect combo for the internal combustion modeler looking to simplify the process of getting telemetry for their model.
Reduce clutter and get back in control with this Combustion Combo from HorusRC.
Gas suite Description
The Gas Suite is a multifunctional unit which is mainly used to monitor the operating state of an internal combustion engine model. It allows you to measure in real-time the operating temperature, RPM, and fuel flow velocity. In addition, the Gas Suite also allows you to control the ignition system manually, allowing the user full control during operation.
Specifications
- Operating Voltage Range: 4.0V~10V
- Measured Range of Speed: 100~100000r/min (Degree of Accuracy: ±2%)
- Measured Range of Flow Velocity: 20~800ml/min (Degree of Accuracy: ±2%)
- Measured range of temperature:
- TEMP1: PT100: -20â~ 310â, Degree of accuracy: ±1%
- TEMP2: NTC: -20â~ 250â, Degree of accuracy: ±1%
- Physical interface: Temp1 & 2, FLOW, CDI pulse In & Out, Channel In, Smart Port
- Weight: 19g
- Dimension: 40*28.8*12.7mm (L*W*H)
Features
- Monitor in real-time environment temperature and operating temperature of the engine.
- Monitor in real-time RPM and the gas flow velocity
- Smart Port enabled and support telemetry data transmission
- Enable and disable the ignition control system manually
- Parameters (Initial quantity of gas, alarm values and etc.) configuration through transmitters and FreeLink (PC)
RX8R PRO Description
An upgraded version based on the RX8R receiver, it has all the same features including redundancy. The Pro version has higher precision and lower latency. Its deviation of PWM is reduced to 0.5us, and the delay of PWM output is 9ms less than that of the X8R in high-speed mode. A feature that deserves mention is the decreased effect of interference caused by the ignition process.
Specifications
- Numbers of Channels: 16CH(1~8CH PWM or 9~16CH PWM from conventional channel outputs, 1~16CH from SBUS)
- With RSSI Output on Board: Analog DC 0~3.3V
- Operating Voltage Range: 3.5V~10V
- Operating Current: 100mA@5V
- Operating Range: full range(>1.5km)
- Firmware Upgradeable
- Servo Frame Rate: 9ms (HS— High-Speed Mode)/18ms (FS—Normal Speed Mode)
- Compatibility: FrSky transmitters/transmitter modules in the D8/D16 mode
- Dimension: 25mm*26.6mm*14.2mm (L*W*H)
- Weight: 14.8g
Features
- Support redundancy function
- Smart Port enabled and supported telemetry data transmission
- Higher precision deviation of PWM
- Decreased Effect of interference caused by the ignition process
- Lower latency on the PWM output
- Strong anti-interference performance
1 x Gas Suite Combustion Modles
1 x RX8R PRO receiver
