Description:
Brand name: Frksy
Item name: D4R-II receiver
Operating Range: full range (>1.5km)
Operating Voltage Range: 3.5~10V
Operating Current: 60mA
Number of Channels: 4
Dimension: 40 x 22.5 x 6mm
Weight: 5g
Compatibility:
Compatible with FrSky two way telemetry modules: DFT, DJT, DHT, DHT-U
Features:
Firmware upgradeable
Lighter weight and physically smaller
Alarm warning on low voltage, poor reception, etc.
One external analog telemetry port and one digital data-stream port (connect to FrSky Sensor Hub FSH-01)
RSSI (PWM) and CPPM output - If CH3 and CH4 are connected by a jumper, CH1 will output CPPM for CH1~CH8, and CH2 will output RSSI (PWM)
English Manual,!
Package Included:
1 x FrSky D4R-II Receiver
