FPV Mini 600TVL 1/4 COMS FOV45° 20mm Lens Camera PAL
Specification:
Item Name: 600TVL Mini FPV Camera
Horizontal definition: 600 TV Line
Video signal system: PAL
Input Voltage: 1S Lipo battery
FOV: 45°
Lens: 20mm
Image Sensor: 1/4 CMOS
Pixels: 2,000,000
White Balance: Auto
Video Output: 1.0Vp-p/75-ohm
Dispaly: Colorful
Minimal Illumination : 0.5 Lux
Video Output : 1.0Vp-p/75Ω
Power Consumption : 90MA ±10%
SNR (Signal to Noise Ratio) : 38dB
DR Dynamic Range : 70dB
Shutter : (N)1/60-1/10000s, (P)1/50-1/10000s
Working Voltage : DC3.3-5.0V
Working Temp. : -5â~55â RH95% Max
Size:12*12mm
Weight: 10g
Features:
-Small size, lightweight
-Low power consumption, high sensitivity, easy to install
Package Included:
1x 600TVL Mini Camera
