Specification:
- Screen Size: Diagonal 0.44 Inches
- Screen Material: LCOS(Liquid Crystal on Silicon)
- Display Color: R,G,B,Vertical Stripe
- Display Pixel: VGA signal (640H × 480V) × RGB, 1670 million colors 922 000 pixel full-color, high-resolution.
- Virtual Screen Size: Equivalent to 2 meters away 48 inches diagonal screen
- Aspect Ratio: 4:3 or 16:9
- Video Signal Input: AV interface or VGA port, composite video signal C-VIDEO (NTSC / PAL standard automatic identification and conversion)
- Power Input: Single +3.3 to 5 volt DC power supply
- Current: <220mA
- Rechargeable Lipo Battery: LP1100
- Contrast: 100:1
- Optical: FOV: 32 degrees / Exit Relief: 20mm / Exit Pupil: 10mm
- Display Gray Rate: >256
- Power Consumption: 60mW
- Storage Temperature: -20°C to 80°C, humidity 95% maximum, without fog
- Operating Temperature: -10°C to 60°C, humidity 90% maximum, without fog
- Humidity range: under 40°C, 80% humidity can work for 240 hours
- Shock: Can withstand the impact even it drops from a height of 3 feet to the ground
- Shake: 20Hz-2000Hz, 6G maximum acceleration, 3-axis (This range of shock can be acceptable)
- Image Board Input Terminals (J3) Leads to Define: AV Terminal (RCA-yellow)
- Life: 80,000 hours
New Functions:
- Adjust the screen brightness and contrast features to adapt to different environments
- A user-friendly full set
- Simple adjustment between monocular viewing angle and glasses
Package Includes:
1 x Monocular Group Set (product shell CNC machining, non-mold)
1 x Power Box (as CNC machining, non-open mode, without batteries, battery model is BL-4CT)
1 x Signal Cable
1 x Sport Headband
1 x Glasses Pocket
1 x Glasses Cloth
1 x Spectacle Case
1 x AV Input Line
1 x Advanced Professional Sports Glasses (sports headband, glasses bag, glasses cloth, myopia box)
1 x Battery
