Specification:
Brand name: Flysky
Item name: FS-TM10 Transmitter
Channel: 10
RF range: 2.408-2.475GHz
RF channel: < 20dBm
RF channel: 135
Bandwidth: 500KHz
2.4GHz system: AFHDS 2A / AFHDS
Modulation type: GFSK
Stick resolution: 4096
Chargeable: No
Low voltage warning: < 4.2V
DSC port: PS2 PPM
Model Type: Airplane / Glider / Helicopter
Antenna length: 26mm (dual antenna)
Power: 6V DC 1.5AA * 4 (not included)
Display: Transflective STN Positive Screen with Backlight
128*64 Pixels
VA 73 * 39mm
LCD white backlights
On-Line Update: Yes
Size: About 17.5 * 3.6 * 19cm
Weight: 421g(including receiver)
Color: Black
Certificate: CE0678, FCC
Receiver: FS A8S / IA10B /IA6B Receiver
Features:
Low Power Consumption: The system is built by using highly sensitive low power consumption components, which maintaining high receiver sensitivity, while consuming as little as one tenth the power of a standard FM system, dramatically extending battery life.
Model Type: Fixed-Wing / Glider / Helicopter / Boat / Drone
2.4GHz System: AFHDS 2A / AFDHS. It can automatic frequency hopping, remote control distance up to 700 meters without interference.
Display: STN transflective display, LCD 128 * 64 Lattice, VA 73 * 39mm, LCD with white backlights.
Bidirectional Communication: Capable of sending and receiving data, each transmitter is capable of receiving data from temperature, altitude and many other types of sensors, servo calibration and i-BUS Support.
Unique ID Recognition System: Each transmitter and receiver has it's own unique ID. Once the transmitter and receiver have been paired, they will only communicate with each other, preventing other systems accidentally connecting to or interfering with the systems operation.
Support Receiver Model: GR3E, R6B, R9B, A3, BS3, BS4, BS6, A6 ,iA6, iA6B, X6B, A8S, iA10, iA10B etc.
Package Included:
1 x FS-TM10 Transmitter
1 x Flysky Receiver
