FlySky FS-i4 2.4G 4CH AFHDS Transmitter With FS-A6 Receiver
Description:
Brand Name: FlySky
Item Name: FS-i4 transmitter with FS-A6 receiver
Specification Of FS-i4 Transmitter:
- Channels: 4
- Model Type: Fixed wing / Glider / Helicopter
- RF Range: 2.4000-2.485GHz
- Bandwidth: 500Khz
- Band: 160
- RF Power: <20 dBm
- 2.4ghz system: AFHDS2
- Modulation: GFSK
- Sensitivity: 1024
- Low Voltage Warning: Yes (< 4.2V)
- DSC Port: PS2 Out (signal: PPM)
- Charger Port: NO
- Antenna Length: 26mm * 2 (Dual antenna)
- Weight: 335g
- Working Voltage: 6V DC / 1.5AA X 4 (Not Included)
- Display Mode: LED indicator
- Size: 174 x 89 x 190mm
- Color: Black
- Throttle: Left/Right(optional)
- Certification: CE0678,FCC
Specification Of FS-A6 Receiver:
- Channels: 6
- Model Type: RC Glider / Heli / Airplane
- RF Range: 2.4055--2.472GHz
- Bandwidth: 500KHz
- Band: 140
- RF Receiver Sensitivity: -105dBm
- 2.4GHz System: AFHDS 2A
- Channel Definition: 4096 grade
- Modulation: GFSK
- Sensitivity: 1024
- Antenna Length: 26mm
- Weight: 13g
- Power: 4.0-6.5V DC
- Size: 45 x 23 x 9mm
- Color: Gray
- Certificate: CE,FCC
Features:
- Reliable,interference free 2.4GHz AFHDS 2A signal operation.
- Ultra light weight design,low power.
- Easy to bind and very fast link-up.
- Has strong passive and active ability of anti-jamming.
- Built-in system of FS-i4 can freely switch between I and II generation system.
- Using linear good all-band gain antenna,covers the whole band width of the antenna bandwidth.
- With V - MIX mixed control system,compatible with many models.
- FS-A6 receiver is compatible with Flysky i4 i6 i10 transmitter.
- FS-i4 transmitter is compatible with Flysky iA10,R9B,R6B,iA6,iA6B,A6,A3,GR3E,GR3F receiver.
- Quick and extremely stable in performance.
English Manual of FS-i4,
FS-A6 match code video,
Package Included:
1x Flysky FS-i4 transmitter
1x Flysky FS-A6 receiver
1x Code line
1x Manual CD
