FLYSKY FS - A8S 2.4GHz 8-channel Mini Receiver

FLYSKY FS - A8S 2.4GHz 8-channel Mini Receiver
Seller: GearBest,


Description:
As a compact one-way receiver designed for multirotors, the FS - A8S uses the AFHDS 2A ( Automatic Frequency Hopping Digital System ) protocol, supports standard 8-channel PPM output and 18-channel iBUS output.

Specifications:
Channels: 8 ( PPM ), 18 ( iBUS )
Model type: multirotor
RF range: 2.408 - 2.475GHz
Bandwidth: 500KHz
RF channels: 135
Receiver sensitivity: -92dBm
2.4GHz system: AFHDS 2A
Modulation type: GFSK
DSC port: PPM / iBUS / SBUS
Transfer method: FHSS
Antenna length: 26mm ( not including brass contacts )
Input power supply: 4.0 - 8.4V
Display method: LED
No ground interference: control distance more than 300m ( transmitting and receiving 1m above the ground )
Working current: 40mA
Channel delay: less than 15ms
Size: 20 x 14 x 5.3mm
Weight: 1.2g
Certificate: CE0678, FCC
Compatible transmitter: FS - i10, FS - i6S, FS - i6X, FS - TM10, FS - TM8

Click here to download the user manual.

Specification

General

Brand: Flysky
Type: Receiver

Dimension and Weight

Package weight: 0.030 kg
Product size (L x W x H): 2.00 x 1.40 x 0.53 cm / 0.79 x 0.55 x 0.21 inches
Package size (L x W x H): 3.00 x 2.40 x 1.50 cm / 1.18 x 0.94 x 0.59 inches

Package Contents

Package Contents: 1 x Receiver, 1 x Cable
