FA-MT01 6-12VDC 100-5500Hz Microphone Pickup Aerial Audio Signal Collection For Camera FPV
Description:
Item name: FA-MT01
Type: Microphone Pickup
Power supply: 6-12VDC
Frequency range: 100-5500Hz
Output: 2.5Vpp/-25db
Red line: connect power anode
Black line: connect power cathode
White line: the output of audio signal, the input of transmission image
For Camera FPV
Features:
This type of microphone has a low noise, high fidelity, wide working voltage range, low power consumption, long transmission distance, etc. Using the implementation audio synchronization with the camera.
Package Included:
1x FA-MT01 Microphone pickup
