Specification:
Brand name: EXUAV
Item name: F4 PRO V2 Flytower
All Board Weight: 20.2g(All 2 PCB)
Total Weight: 25.3g(Includes heat sink and screws)
Installation Height: 14mm(Includes heat sink)
Screws: M3X18mm
Recommended Rack Plate Thickness: Not more than 3mm(3mm above the appropriate extension of the screw)
4 In 1 50A BLHeli_32 ESC:
PDB: Integrated
Battery Monitoring: Integrated
FC Power: Integrated
Operating Voltage: 2-5S Lipo
Maximum continuous operating Current: 4X50A
Maximum instantaneous operating Current: 4X60A(10 Seconds)
Dshot 1200: Yes
Board Size: 36X36mm
Weight: 8.8g
FC&VTX Board:
Firmware Vision: F4 Version(EXUAV F4 PRO)
Configure: BetaFlight
VTX Power: Off/25/200/600mW
Chanel: 48CH(IRC Tramp)
OSD Firmware: Betaflight OSD
Video Camera Voltage: Any stand by 5V Video Camera
Board Size: 36X36mm
Weight: 11.4g(Includes heat sink)
Package Included:
1X F4 Pro V2 FC AIO VTX Module
1X 50A BLheli_32 4 In 1 ESC
