30A-6S:
Description:
Brand Name: Emax
Item Name: Simonk Series ESC
Current: 12A 20A 25A 30A 40A available
Input: 2-3S LiPo
Item continuous current burst current (10A) battery(cell) Dimension Wight(g) BEC mode BEC output programmable 12A 12A 15A 2~3 22*17*7 8 linear 1A/5V YES 20A 20A 25A 2~3 55*28*7 28 linear 2A/5V YES 25A 25A 30A 2~3 55*28*7 28 linear 2A/5V YES 30A 30A 40A 2~3 55*28*7 28 linear 2A/5V YES 40A-UBEC 40A 50A 2~6 73*28*12 41 switch 3A/5V YES
Features:
Based on Simon K firmware, further optimized to perfect drive performance.
Low-voltage protection, over-heat protection and self-check functions.
Separate power supply for MCU and BEC, enhancing the ESC’s ability of eliminating magnetic interference.
Parameters of the ESC can be set via program card or transmitter.
Throttle range can be set to be compatible with different receivers.
Equipped with built-in BEC.
Max speed: 210,000 rpm for 2-pole, 70,000 rpm for 6-pole, 35,000 rpm for 12-pole.
Note: this ESC can not work with pixhawk flight controller.
Emax ESC Manual,!
Package Included:
1 x Emax ESC
