Description:
Brand Name: Emax
Item Name: BLHeli Series ESC
Current: 6A 12A 20A 25A 30A available
tem continuous
current burst current
(10A) battery
(cell) Dimension Wight(g) BEC mode BEC output programmable EMAX BLHeli-6A 6A 8A 1~2 22×13×5.5 6 linear 0.8A/5V YES EMAX BLHeli-12A 12A 15A 2~4 42×20×8 11 linear 1A/5V YES EMAX BLHeli-20A 20A 25A 2~4 52×26×7 28 linear 2A/5V YES EMAX BLHeli-25A 25A 30A 2~4 52×26×7 28 linear 2A/5V YES EMAX BLHeli-30A 30A 40A 2~4 52×26×7 28 linear 2A/5V YES
Features:
Based on BLHeli firmware, further optimized to the perfect drive performance.
Low-voltage protection, over-heat protection and throttle signal loss protection.
Separate power supply for MCU and BEC, enhancing the ESC’s ability of eliminating magnetic interference.
Parameters of the ESC can be set via program card or transmitter.
Throttle range can be set to be compatible with different receivers.
Equipped with built-in linear BEC or switch BEC.
Max speed: 210,000 rpm for 2-pole, 70,000 rpm for 6-pole, 35,000 rpm for 12-pole.
Emax ESC Manual,!
Package Included:
1 x Emax ESC
