Electronic Servoless Retractable System Plastic Rotational Parts 54g PZ-15091
Description:
The easiest way to put retracts in your plane. No need to install a control box, messy wiring or a complicated air system. Just screw in the retracts, connect to your Rx and you are ready!
Reliable servo mechanism with metal gearing and a high torque motor ensures trouble free flying!
Why bother with air systems when you can now have a realistic and reliable electric unit at a fraction of the price?!
Landing gear not included with the servoless retractable system.
Specification:
Item Name: Servoless retractable system
Item NO.: PZ-15091
Material: Plastic
Gear: Metal
Working voltage: 4.8~6V
No-Load Speed: .08s/60deg (4.8v) - 0.6s/60deg (6v)
No-Load Running Current:150±30mA (4.8v) - 160±30mA (6v)
No-Load Running Life: >10000 times (4.8v) - >8000 times (6v)
Stall Torque: 2.9±0.2kg-cm (4.8v) - 3.1±0.2kg-cm (6v)
Stall Current:1.2±0.1A(4.8v) - 1.4±0.1A (6V)
Idle Current: 3±1mA
Angle limit: 90 degree when retracted
Operating temp: -10~50C
Dimensions: 73.5x44x28mm
Weight: 54g
Shaft size: 5mm
Mounting area size: 44mm x 41mm
Length: 74mm
Signal Cable: 150mm,JR plug
Not suitable for a plane heavier than 4.7kg
Features:
Robust landing gear strut and mounting bracket
Built-in 10 seconds over current and jamming protection
Integrated electric motor with a micro PCB
Double shock absorption design, completely protect the gears
Auto 90 degree twist when retracted
Package Included:
1x Servoless retractable system
