EachinePilot Micro GPS And Compass Module U-BLOX 7 For RC Multirotor
The New banggood EachinePilot Micro GPS and Compass module is perfect for the small class multirotor, planes or even standalone OSD application. Featuring the new u-Blox MAX 7 chipset and a matched 15x15 dual amplified ceramic antenna, this micro GPS is packing full size power. The micro GPS also has the Honeywell HMC5883 Compass for remote location, to get your compass away from sources of interference. All this power and features, all at just 8g, the EachinePilot Micro GPS all so comes with cables for both the 5 pin EachinePilot Mega (APM), and the 6 pin EachinePilot 32 (Pixhalk). This Micro GPS is also perfect for the MWC and Naze32 applications as well.
PX4/Pixhawk is an independent, open-source, open-hardware project aiming at providing a high-end autopilot to the academic, hobby and industrial communities (BSD licensed)
The reference to APM refers to the ArduPilot project, a family of open source autopilots based on the Arduino open source computing platform, developed by 3DR and the open source community. It consists of a choice of ArduPilot Mega (APM) electronics and a range of free software versions for different vehicles and is governed by an open source creative commons license.
Description:
Dimensions (mm): 20 (width) x 22 (length) × 8.5 (H)
Weight (g): 8.2 (without cable)
GPS module: u-blox MAX-7Q
Onboard interface: Molex 1.25mm-4Pin(I2C), 6Pin(UART)
Features:
Active ceramic antenna, 15 × 15mm, comes with two LNA low-noise amplifier.
UART interfaces with EMI protection design, the RXD port can be compatible with 5V level signal input.
Build in HMC5883 compass I2C interface.
HG-U06 GPS with a standard UART (TTL) serial interface, common in most of the flight control.
Default setting Baud rate: 38400, update rate: 10hz
6ch u-blox 7 multi-GNSS (GPS, GLONASS, Galileo, QZSS and SBAS) engine.
Package included:
1 x GPS module
1 x I2C 4pin cable
1 x UART 6pin to 5pin cable (for APM)
1 x UART 6pin to 6pin cable (for PX4)
