Working Channel selection:
Note: “p” indicates “POW”, when “POW” is ON, video TX supply power to outside DV, and B light is on at the same time.
Description about LED light:
A is on indicates the power is normal; B is on indicates supplying power for an outside DV.
Diagram of connection:
Description:
Item name: MX-VTX-C 5.8GTransmitter
Output power:150mW
8 working channel
Super tiny:25.8*21.0*6.8m (not including antenna)
Super light:4.5g (including antenna)
Working voltage:3.0~4.2V(1S)
Working current: 660mA/3.2V; 560mA/3.6V;480mA/4.0V
Max current supply for outside DV: 500mA
Over current protection for outside DV
Support protection of power reverse connection
IPX antenna port
Features:
MX-VTX-C is a super tiny and light video transmitter
Micro 5.8G video TX specially designed for 1S power supply.
Supply current of the built- in DCDC can reach 1.5A at the most, it can power both video TX and the outside DV.
it is exactly the one for those 1S multirotor copter which is very strict on flight weight.
Package Included:
1 x MX-VTX-C 5.8GTransmitter
