DYS SN20A Mini 20A SimonK ESC&BE2204-2400KV Brushless Motor&6045 Propeller
Description:
Brand Name:DYS
Item Name:SN20A ESC+BE204-2400KV Motor+6045 Propeller
Quantity:four ESC+four Motor+four Propellers
SN20A ESC:
Come with SimonK:Yes
BEC: OPTO
Input voltage: 2-4s Lipo
Signal Frequency:20-500Hz
Outout PWM Frequency:18KHz
Application:Compatible with SimonK and BLHeli
Size(LxWxH): 23x12x4.5mm
Weight:7.6g
6045 Propeller:
Material:Plastic
Inch:6
Pitch:45
Color:Black,Green,Blue,Red
Fit for 250mm Mini quadcopter
BE2204-2400KV Motor:
Pull:360g
KV:2400
Configu Ration:12N14P
Stator Diameter:22mm
Stator Length:4mm
Shaft Diameter:3mm
Outside Shaft Diameter:2.0mm
No.of Cells(Lipo):2-3S
Maximum Continuous Current:9.4A
Maximum Continuous Power:69.6W
Internal Resistance:0.013Ω
Weight:23g(Not included Wires)
Motor Dimensions(Dia.*Len):27.5x16.5mm
Features:
SN20A ESC:
Specially for Multi-copter, throttle respond fast
Suit for throttle, which can compatible well with motor
Throttle signal is twisted pair cable, reduce the crosstalk while the signal transfer by the copper wire and flight more stable
The maximum refresh frequency up to 500Hz throttle signal, compatible with all flight controls
Use new process ultra-low resistance MOSFET with miniaturization, and all flashes are N MOS with high withstanding current
Minaturization design, SN16/20A with high performance capacitor fliter on the board, weight reduce to 2g, also already thicken the PCB copper specially and low
BE2204-2400KV Motor:
With high quality materials and maching
Light weight but high payload
Longer flight time for multirotors
Notice:Comes with 15cm silicone wire, 3.5mm banana head.
Package Included:
4x SN20A ESC
4x BE2204-2400KV Motor
4x 6045 Blades
