DYS SN20A Mini 20A SimonK ESC&BE1806 2300KV Golden Motor&5030 Propeller
Description:
Brand Name:DYS
Item Name:SN20A ESC+BE1806 2300KV Motor+5030 Propeller
Quantity:four ESC+four Motor+four Propellers
SN20A ESC:
Come with SimonK:Yes
BEC: OPTO
Input voltage: 2-4s Lipo
Signal Frequency:20-500Hz
Outout PWM Frequency:18KHz
Application:Compatible with SimonK and BLHeli
Size(LxWxH): 23x12x4.5mm
Weight:7.6g
5030 Propeller:
Color:Black,Green,Blue,Red
Material:Plastic
Inch:5
Pitch:30
Fit for 250mm Mini quadcopter
1806 2300KV Brushless Motor:
Height: 0.85 inches (21.5mm)
Width: 0.90 inches (23mm)
Weight: 18 grams
RPM/V: 2300KV
Output shaft diameter: 2
Voltage: 2-3S
Battery: 2-3S lithium polymer
Max.current: 7.6A
Max.power: 84.4W
Mounting pattern: 2x 12mm and 2x 16mm
Motor mount hole size: M2
Features:
SN20A ESC:
Specially for Multi-copter, throttle respond fast
Suit for throttle, which can compatible well with motor
Throttle signal is twisted pair cable, reduce the crosstalk while the signal transfer by the copper wire and flight more stable
The maximum refresh frequency up to 500Hz throttle signal, compatible with all flight controls
Use new process ultra-low resistance MOSFET with miniaturization, and all flashes are N MOS with high withstanding current
Minaturization design, SN16/20A with high performance capacitor fliter on the board, weight reduce to 2g, also already thicken the PCB copper specially and low
1806 2300KV Brushless Motor:
Low vibration motor great for flying
To make aircraft more stable
Less operating noise
More efficient
Bearings long life
Package Included:
4x SN20A ESC
4x 1806 2300KV Motor
4x 5030 Blades
