DYS SE1407 3600KV Brushless Motor Set

DYS SE1407 3600KV Brushless Motor Set
Seller: GearBest,
Main Features:
- New design with imported NMB bearing
- N52 magnet and 0.2mm lamination
- Powerful, with 450g thrust to work with 4-inch propellers
- Especially designed for FPV racers

Specifications

General

Brand: DYS
Type: Motor Set

Motor

KV: 3600
Stator Diameter: 14.0mm
Stator Length: 7.0mm
Shaft Diameter: 3.0mm
Motor Dimensions: 18.3 × 16.0mm
No. of Cells: 3 - 4S
Max. Continuous Current (A): 17.3A
Max. Continuous Power (W): 256.0W
Internal Resistance: 0.16ohms

Dimension and Weight

Product weight: 0.014 kg
Package weight: 0.080 kg
Package size (L x W x H): 8.00 x 6.00 x 4.00 cm / 3.15 x 2.36 x 1.57 inches

Package Contents

Package Contents: 1 x CW Motor, 1 x CCW Motor, 12 x Screw, 4 x Nut
