DYS BE2208 1400KV Brushless Motor
DYS BE2208 1400KV brushless motor is with Kawasaki, Japan 1200 # 0.2mm high efficiency silicon steel and 40UH high temperature powerful magnet. Selected the Japanese NSK pure imported bearings to reduce motor vibration, shell using high-precision CNC machining and professional balancing test, making concentricity, balance is greatly enhanced. DYS BE2208 1400KV high-end brushless motor perfectly compatible with more than 99% of available brushless ESC.
Description:
Brand Name: DYS
Item No: BE2208
Item name: 2208 1400KV Brushless Motor
KV: 1400KV
Stator Diameter: 22mmKV: 1400KV
Stator Length: 8mm
Shaft Diameter: 3.17mm
Motor Dimensions(Dia.*Len): Φ28×26mm
Weight: 44g
No.of Cells(Lipo): 2-4S
Max Continuous current(A): 26A
Max Continuous Power: 384W
Internal Resistance: 0.106Ω
Test data(for reference only):
