DYS 32Bit BaseCam BGC V3.0 3 Axis Brushless Gimbal Controller With Protection Case For RC Drone - 79.99 €

DYS 32Bit BaseCam BGC V3.0 3 Axis Brushless Gimbal Controller With Protection Case For RC Drone
Seller: Banggood,
Free shipping aviable, Registered postage from 25 €

DYS 32Bit BaseCam BGC V3.0 3 Axis Brushless Gimbal Controller With Protection Case


Specifications
Brand: DYS
Size: Approx. 52x55mm/ 2.05x2.17"
Mounting Hole Diameter: 3mm/ 0.12"
Power Supply Voltage: 8–25 V
Maximum Motor Current: 1.5 A
5V Output Current to Power External Devices: Up to 1 A
Features
Upgradeable 32Bit BGC V3.0, with a protection case
32bit MCU--ARM Cortex M4. Effectively calculates the complex tasks for 3-axes stabilization
Allows camera control with the RC or analog joystick
Use several switchable profiles for different modes of operation
Supports variety of RC protocols: PWM, Sum-PPM, spektrum and s-bus
Battery voltage monitoring, compensating voltage drop in the PID-regulator
Low battery alarm (output to 5V active buzzer)
Increased number of inputs for controlling signals + 3 additional reserved input/output AUX1-AUX3
Can supply up to 1A current for external devices on the 5V power line
Dedicated UART-socket to connect optional Bluetooth module
Reverse-polarity protection, overheat and overcurrent protection
USB interface for the PC connection, to configure, control and upgrade firmware
Graphical user interface to manage the settings. Windows / OS X / Linux versions
Control through the Serial-protocol using dedicated API
Improved attitude estimation algorythms
Optional second IMU, that will increase the short-term precision of the stabilization 10x-30x times and will make stable work in any frame position
Package Included
1 x Gimbal Controller
