Dualsky VR Pro High End Linear Regulator w/ New FSS-4 Failsafe Switch For 50CC Gas RC Airplane
Description:
Brand Name: Dualsky
Item Name: VR Pro High End Linear Regulator
Input Voltage: DC5.3V -8.4V, MAX10V (2S LiPo)
Output Voltage: 5V, 6V, 7.4V (Switchable, Tolerance + 3%)
Output Current: DC 0 -10A (Vin-Vout =1V)
Minimum Differential Voltage: ≤0.2V
Power Effect: 0.3%
Voltage Effect: 0.3%
Output Ripple: ≤ 2mV
Size: 53mm X32mm X18mm
Weight: 30g (excluding accessories)
Design Features:
Miniaturization design, input & output port using horizontal row,plug-and-play;
Built-in tri-color input voltage monitor, low voltage memory function;
Support HV servos (7.4V), output voltage is switchable;
Includes FSS-4 lightweight switch(#46814), VR Pro also supports FSS-3, the failure safety switch with status indicator (#46813);
Equipped with heat sink, external cooling fan (#46816) can be connected as an option;
Support up to 6pcs of 30kg digital servo;
Support up to 6pcs of 30kg digital servo;
Can be used on the largest 8kg model aircraft, eg. 50cc Gasoline Powered Aircraft.
Electrical Features:
Linear regulator, no interference, low ripple;
Double MosFET output, independent linear control IC, high output current capability;
Large heat sink, good heat dissipation and high overload capacity;
Built-in MCU precisely controls FSS-3 and internal voltage;
Fail safe design, ensuring Non-stop work;
Low dropout design makes fully use of the cell's capacity, especially on HV mode;
SMT process, ensureing the quality;
Input & output port all use high quality tantalum capacitors;
Dualsky Shanghai factory assembled, fully tested before dispatch.
English Manual,
Package Included:
1x Dualsky VR Pro High End Linear Regulator
English Manual,
Package Included:
1x Dualsky VR Pro High End Linear Regulator
