DIY FPV 5.8GHz 200mW Integrated 600TVL Camera Transmitter For Hubsan & RC Model
CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8 MHZ 5705 5685 5665 5645 5885 5905 5925 5945 CH1 0 1 0 1 0 1 0 1 CH2 0 0 1 1 0 0 1 1 CH3 0 0 0 0 1 1 1 1
Black represents the positions of the DIP switch.
Description:
Item name: 600TVL Camera Transmitter
Frequency: 5.8GHz
Voltage: 3.7V~5V
Current: 350mA
Voltage: 3.7V~5V
Current: 350mA
Transmit power: 200mW
Weight: only 3g
View angle: 70°
View angle: 70°
Usage: All types of RC Model
Note: the distance of receiving signal for this item is about 100m, but it authenticly according to the surroundings, so it would be more or less meters when actual operation.
The package doesn't include a battery, you need to buy a 1S battery in addition.
Note: the distance of receiving signal for this item is about 100m, but it authenticly according to the surroundings, so it would be more or less meters when actual operation.
The package doesn't include a battery, you need to buy a 1S battery in addition.
Package included:
1 x camera transmitter
1 x single head cable
1 x charging adaption cable
