DIY Assemble 2206 2-4S Brushless Motor with Motor Cap Banana Plug - 6.99 €

DIY Assemble 2206 2-4S Brushless Motor with Motor Cap Banana Plug
Seller: Banggood,
Free shipping aviable, Registered postage from 25 €


DIY Assemble 2206 2-4S Brushless Motor with Motor Cap Banana Plug













Test Table:
Voltage
(V) Current
(A) Pull
(G) Power
(W) EFP
(g/w) Propeller 12 2.0 63 24.000 5045 3-Blade 12 4.0 220 48.000 4.583 5045 3-Blade 12 6.0 310 72.000 4.306 5045 3-Blade 12 8.0 390 96.000 4.063 5045 3-Blade 12 10.0 470 120.000 3.917 5045 3-Blade 12 11 505 132 3.826 5045 3-Blade 12 13 580 156 3.718 5045 3-Blade 12 14 615 168 3.661 5045 3-Blade 12 16 680 192 3.542 5045 3-Blade 12 20 810 240 3.375 5045 3-Blade 12 22 850 264 3.22 5045 3-Blade
Specification:
Item Name: DIY Assemble 2205 Brushless Motor

Height: 18.9mm
Width: 28mm
Shaft diameter: M5
Motor mount hole size: M3
Copper Wire: 0.42MM ( Diameter)*2.8M (Length)
Battery: 2-4S lipo battery
Internal resistance: Ω
CW screw thread motor comes with Siliver cap
CCW screw thread motor comes with Black cap


Package Included:
1x Assemble 2206 Motor
1x Cap
1x Banana Plug for Motor
