Description:
Model-specific DC-DC step-down module (supports 2S ~ 5S lithium polymer), DIY mobile power, car power, communications equipment supply, and occasions require specific size and weight. Use integrally molded power inductor and synchronous rectifier control chip, smaller and more efficient.
Specifications:
Model: Mini-360 ( mini DC-DC synchronous rectifier buck module)
Modular nature: Non-isolated Buck
Rectification: Synchronous rectification
Input voltage: DC 4.75V-23V
Output voltage: DC 1.0V-17V (Adjustable, Output < Input)
Output current: Rated current 1.8A (3A MAX, can not be prolonged)
Output ripple: 30mV(no-load)
Load regulation: ±0.5%
Voltage regulation: ±2.5%
Operating Temperature: Industrial (-40℃ ~ +85℃)
Short circuit protection: No(Please do not short-circuit)
Input Reverse protection: No(Can not be reversed)
NOTE: This can't be used to step up Voltage. Output voltage is always smaller than input!
Size: 17*11*4mm (L*W*H)
Package Included:
1 x Mini DC-DC Converter Step Down Module
