Darts180 180mm 3K Carbon Fiber Matte Twill Mini Frame Kit For Multicopter Quadcopter
Description:
The whole machine is relatively light,easy to control, suitable for stunts, tumbling and other actions, the flight time is 9 minutes.
Specification:
Whellbase:180mm
Material:3K full carbon fiber matte twill
Thickness:1mm
Weight:52g (without electronics)
Accessories:
CCD Camera Mounting Plate:25mm(width)*30mm(length)*90 degree
CCD Camera Mounting Plate:25mm(width)*30mm(length)*35 degree
Gasket thickness:1mm
Single plastic damping ball
Recommend parts (package not include):
Propeller:4 inch
Motor:1306-3100KV brushless motor
ESC:6A-12A
Flight controller:openpilot CC3D standard bent needle or miniCC3D bent needle
Battery:6A ESC:2S 850MAh-1000MAh or 10A-12A ESC:3S 1000MAh-1500MAh
Package Include:
1 x Darts180 3K Carbon Fiber Matte Twill Frame kit
1 x CCD Camera Mounting Plate:25mm(width)*30mm(length)*90 degree
1 x CCD Camera Mounting Plate:25mm(width)*30mm(length)*35 degree
4 x Gasket
4 x Single plastic damping ball
Assembly Test:(not include the following accessories)
Propeller: FC4045 CW/CCW propeller
Motor: RCtimer 1306-3100kv
ESC: EMAX 12A ESC
Flight controller: miniCC3D bent needle
Battery: 3S-1200mah
FPV Camera Lens: Eachine CCD 700tvl 148 Degree Camera Lens
FPV transmitter: 5.8G 200mW FPV Transmitter
Weight(After installed):273g
