CYS-S0009A 9g Analog Metal Gear Servo is designed and manufactured for RC Car Boat Airplane. Small size and light weight is conducive to the driving of RC models. And its high strength design increase its durability. If you want to get a better RC playing experience, CYS-S0009A servo is a good choice!
Features:
Wide operating voltage-4.8V to 6V
Small size and light weight, about 9g only
Perfectly tailored to RC Car, RC Boat, RC Airplane
High sensitivity and responsiveness, flexible operation
Easy to install, smooth movement, and exquisite workmanship
Specifications:
Specifications:
Item No. CYS-S0009A
Weight 10g
Size 22.3*11.8*26.3mm
Control System (+)Pulse Width Control 1500usec Neutral
Required Pulse
Operating Voltage 4.8~6.0Volts
Operating Temperature Range (-)10 to +50 degree C
Operating Speed (4.8V) 0.12sec/60° at no load
Operating Speed (6.0V) 0.10sec/60° at no load
Stall Torque (4.8V) 1.2kg.cm
Stall Torque (6.0V) 1.5kg.cm
Operating Angle 45deg.one side pulse traveling 500 usec
360 Modifiable No
Direction Anticlockwise/Pulse Traveling 1000~2000usec
Current Drain (4.8V) 10mA/idle and 100mA no load operating
Current Drain (6.0V) 10mA/idle and 120mA no load operating
Stall Current 900mA/1A
Dead Band Width 4usec
Motor Type 3 Pole Ferrite Drive
Bearing Type No
Horn gear spline 21T
Gear Type Metal
Important Notes:
-Refer to the figure when installing the servo accessories.
-For engine powered airplanes and boats, rubber must be used to reduce vibration.
- Please choose correct model for your application.
-Torque over-loaded will damage the servo's mechanism-.
- Keep the servo clean and away from dust, corrosive gas and humid air.
Package Included:
1 * Analog Metal Gear Servo
1 * Spare Parts Set
