Description:
It's replaceable tiny SERVO for TFL small bolt E13 rc boat.
size:33 x 12 x 21mm
Control System (+)Pulse Width Control 1500usec Neutral
Required Pulse
Operating Voltage 4.5~6.0Volts
Operating Temperature Range (-)10 to +50 degree C
Operating Speed (4.8V) 0.12sec/60° at no load
Operating Speed (6.0V) 0.10sec/60° at no load
Stall Torque (4.8V) 1.2kg.cm
Stall Torque (6.0V) 1.5kg.cm
Operating Angle 45deg.one side pulse traveling 500 usec
360 Modifiable No
Direction Anticlockwise/Pulse Traveling 1000~2000usec
Current Drain (4.8V) 4mA/idle and 260mA no load operating
Current Drain (6.0V) 5mA/idle and 300mA no load operating
Stall Current 800mA/900mA
Dead Band Width 4usec
Motor Type 3 Pole Ferrite Drive
Bearing Type No
Horn gear spline 21T
Gear Type Plastic
Connector Wire Length 180mm
Wire info Brown/Black = Negative
Red = Positive
Orange/White = Signal
Package Included:
1 x tiny SERVO set
