CYS-S0006 Mini Micro Analog Servo is suitable for indoor slow flyers, electric park flyers, RC electric 3D airplanes (Shockflyer, Blitz, etc.) and micro electric RC helicopters. It is designed for most brands of radio equipment including JR, Futaba, GWS, Airtronics & Hitec. And its high strength design increase its durability. If you want to get a better RC playing experience, CYS-S0006 servo is a good choice!
Features:
Wide operating voltage-4.8V to 6V
Small size: 21.5 * 11.8 * 22.7mm, light weight: about 6g
Perfectly tailored to micro RC Car, RC Boat, RC Airplane
Stall torgue of 1.0kg.cm (13.89oz / in) / 1.2 kg.cm (16.67oz / in)
Smooth movement, powerful torque and exquisite workmanship
Specifications:
Brand: CYS
Model: CYS-S0006
Name: CYS-S0006 Analog Servo
Dead Band: 5μsec
Operating Voltage: DC 4.8-6.0V
Operating Speed (4.8V): 0.14sec / 60 degrees
Operating Speed (6.0V): 0.12sec / 60 degrees
Stall Torque (4.8V): 1.0kg.cm (13.89oz / in)
Stall Torque (6.0V): 1.2 kg.cm (16.67oz / in)
Running Current(4.8V): 120mA
Running Current(6.0V): 140mA
Stall Current(4.8V): 390mA
Stall Current(6.0V): 460mA
Idle Current(4.8V): 10mA
Idle Current(6.0V): 10mA
Weight: 6g
Dimensions: 21.5 * 11.8 * 22.7mm
Note: There could be a few deviations due to manual measurement, thank you for your attention
Package Included
1 x CYS-S0006 Servo
1 x Spare Parts Set
