CUAR WTR24 WiFi to XBEE/SX/XTEND/P900 Data Transmission Module For UAV Ground Station
WTR is cuav launched a new application in UAV ground station module for transmitting end WiFi transmission speed, the ground end of digital data into wireless WiFi data, realize the computer or mobile phone WiFi wireless connection UAV, instead of the traditional speed Bluetooth transmission module, to achieve a more reliable and convenient
FAQ common problems
WTR's WiFi name and password
SSID is cuav wtr_xxx (XXX is generated according to the internal MAC address)
WiFi password: cuavwtr666 (lowercase)
How to modify the WiFi name and password of WTR?
Modified by downloading the cuav hflight app http://fw.cuav.net/apk/HFlight.apk
Modified by downloading the cuav hflight app http://fw.cuav.net/apk/HFlight.apk
Support baud rate type
Only 57600 baud rate is supported at present
Specification
wireless standardsIEEE 802.11g,IEEE 802.11btransmission speed11g: Up to 54Mbps, 11b: up to 11MbpsWIFI communication
distance
150-500 meters (depending on computer or mobile phone)baud rate57600attended modeUDP:14550channel range1 - 13 (default 11 channels)frequency range2412 - 2472MHztransmitting power18dbmWIFI typeSMA TYPEWIFI safetyWPA/WPA2 security mechanismcommunicating protocolMalvink+ pass-throughtraffic rate57600working voltage5V +- 0.25V
working current100MAworking temperature-20 - 50°COperation humidity10% - 90%RH (non condensing)Storage Temperature-40 - 80°CStorage Humidity5% - 90%RH(non condensing)Connector JST-GH 1.25mm 6P WIFI Information SSIDCUAV_WTR_XXXXXXPasswrdcuavwtr666wireless standardsIEEE 802.11g,IEEE 802.11btransmission speed11g: Up to 54Mbps, 11b: up to 11MbpsWIFI communication
distance
150-500 meters (depending on computer or mobile phone)baud rate57600attended modeUDP:14550channel range1 - 13 (default 11 channels)frequency range2412 - 2472MHztransmitting power18dbmWIFI typeSMA TYPEWIFI safetyWPA/WPA2 security mechanismcommunicating protocolMalvink+ pass-throughtraffic rate57600working voltage5V +- 0.25V
Features
Wireless forwarding interconnection
In particular the UAV operations, often require long-distance communication link number, the number of long-distance transmission can only be connected with traditional computer communication through the cable, this will enable the operator to set up ground station in temporary communication is constrained.
After using WTR, these problems do not return, WTR will end ground digital TTL signal into WiFi signal, connected via mobile phone or
computer, direct transfer can be set up in height to the ground, thus the UAV communication distance farther, more stable.In particular the UAV operations, often require long-distance communication link number, the number of long-distance transmission can only be connected with traditional computer communication through the cable, this will enable the operator to set up ground station in temporary communication is constrained.
After using WTR, these problems do not return, WTR will end ground digital TTL signal into WiFi signal, connected via mobile phone or
Support equipment
TR can convert the TTL signal into WiFi hotspot, and through the UPD transmit and receive support for computer and mobile phone connecting multiple devices at the same time
Built in fault tolerant algorithm
In practical application, the signal is not ideal, prone to incomplete data and disorder of the built-in WTR module mavlink flight data checking and fault tolerant algorithm with high performance, the algorithm will be two times the processing of sending and receiving data, avoid the incompleteness of data and data errors.
Package Included
1 x CUAR WTR WiFi Module
