CT210-PRO 2.4G 1000mW Transmitter Receiver Combo for FPV Racing
Wiring diagram:
Specification:
Model: CT210
Voltage range: 7-27v
Transmit power: 1000mW / 30DB
Transmitter current: 12V-300mA
Operating frequency: 2.4GHz
Sensitivity: -93dB
Antenna gain: 4dB
Antenna net weight: 24g
Transmitter net weight: 39g
Receiver net weight: 67.5g
Receiver size: 62*45*19mm
Transmitter size: 33 * 56 * 17mm
Transmitter net weight: 39g
Receiver net weight: 67.5g
Receiver size: 62*45*19mm
Transmitter size: 33 * 56 * 17mm
Frequency range: CH12.370 CH12.390 CH12.414 CH12.432
CH12.450 CH12.468 CH12.490 CH12.512
Features:
Excellent heat dissipation
COMS / CCD camera with 5V-2A power supply
Ultra-light weight: 39g ultra-light weight
Ultra small size: volume 33x56x17mm
Ultra low power consumption: 12V case only 300ma current
Air switching frequency: support air switching frequency, more convenient operation
Support three-way video switch: support three-way video switch
Wide voltage input: 7-27V wide voltage input design, support 2-6S battery direct power supply
Package included:
1 x Transmitter
1 x Receiver
Package included:
1 x Transmitter
1 x Receiver
