Crius All In One Pro v2.0 Multi-Copter Flight Control Board - 42.65 €

General:
Dimension: 50mmX50mm
Height: 11.6mm
Weight: 14.2g
Fixing hole spacing: 45mm
Hole diameter: 3mm

Features:
Supported MegaPirateNG and MultiWii firmware
Up to 8-axis motor output
8 input channels for standard receiver
4 serial ports for debug/Bluetooth Module/OSD/GPS/telemetry
2 servos output for PITCH and ROLL gimbal system
A servos output to trigger a camera button
6 Analog output for extend device
A I2C port for extend sensor or device
Separate 3.3V and 5V LDO voltage regulator
ATMega 2560 Microcontroller
MPU6050 6 axis gyro/accel with Motion Processing Unit
HMC5883L 3-axis digital magnetometer
MS5611-01BA01 highprecision altimeter
FT232RQ USB-UART chip and Micro USB receptacle
On board logic level converter
Match the standard of RoHS

Flight mode for Multiwii:
One of the following basic mode
Acro
Level
Alt Hold
Head Lock
Optional mode
HeadFree (CareFree)
GPS Hold (Need GPS receiver or Extend Board)
GPS Back to home position (Need GPS receiver or Extend Board)

Flight mode for MegaPirate:
Acro
Alt Hold
Simple
Loiter (uses GPS)
Guided (uses GPS)
Position (uses GPS)
Circle (uses GPS)
RTL (uses GPS)
Auto(uses GPS)
Follow Me(uses GPS)

Input power selection:
One of the following way
Connect 5V power cable from ESC or UBEC to the ESC/Servo port, the J1 jumper must be closed.
Connect 5V~12V power cable to the extend power port, the J1 jumper must be removed.
When using Extend Board, AIO PRO must be powered from the extend power port.

Package Include:
1 x Crius All In One Pro v2.0 Multi-Copter Flight Control Board
