Corona CS238MG Thin Metal Wing Analog Servo
Description:
Brand:Corona
Item:DS238MG Thin Metal Wing Digital Servo
Model: CS238MG
Operating Voltage: 4.8V / 6.0V
Operating Current: 300mA / 400mA
Operating Speed: 0.15sec.60º/ 0.14sec.60º
Stall Torque: 4kg.cm / 4.6kg.cm
Size: 29X13X30mm
Weight: 22g
Dead Band: ≤5uSec
Operating Travel: 40º/one side pulse traveling 400us
Potentiometer: 3 slider/Direct Drive
Ball bearing: MR106
Gear: Metal
Connector wire: 215mm
Operating Temperature Range: -20c+60c
Package Included:
1 xDS238MG Thin Metal Wing Digital Servo
