Cheerson CX-20 CX20 RC Quadcopter Parts Camera 720P 5 Mega-pixel
Description:
Brand: Cheerson
Item name: Camera 720P 5 Mega-pixel
Pixel: 5 mega
High speed 720P60fps
Camera: simplified version
Optional: MIC, boost
Output: no USB output
Key: manumotive
Function: remote control photograph, video.
Picture resolution: 2592×1944, JPEG
Video resolution: AVI, 720p = 1280x720 pixels (16:9), 60 FPS
Maximum support TF card: 32GB (the data of pictures are stored in the TF card, one needs to use a card reader to read data. We recommend you to use above C4 TF card.)
Technical parameters:
Use welded FPC FFC, 5Mega CMOS sensor
High-speed dynamic video, instantly response to light and dark environments.
Ultra-low light sensitivity: 0.84 V/lux-sec
Camera lens: fixed focus
Standard: 8×8MM
Point of view: FULLHD 70°± 5°
Voice frequency: built-in microphone
Intervalometer: center weight
White balance: automatic
Master control: IC
PCB size: 43×18MM
Power supply and remote control signal input:
Starting up: power on the machine start automatically, if the light on red first, and off automatically after traffic lights flashing 6 times, this indicates not detected TF card or TF card is full.
Standby: a red light on long time
Input voltage: 3.7V~5.0V
Standby current: ≈165mA
Working current: ≈200~250mA
Package included:
1 x camera
