Description:
Working Voltage : DC2.4 - 3.6V
Working Frequency: 2400 - 2483.5MHz
Modulation System: FSK/GFSK/ASK/OOK/MSK
Maximum Output Power : +22dBm 200mW
Receiving Sensitivity -115dBm 1.2 Kbps
Emission Current <300mA
Receiver Current : <30 mA
Standby Current: 5uA
Transmission Rate : 1.2-500Kbps
Data Interface :SPI Interface
Maximum Communication Distance : 1.5Km +22dBm,1.2Kbps in visual range
External Antenna Impedance : 50ohm
Storage Temperature : -50 - 150°C
Operating Temperature : -40 - 85 °C
Dimension:31.3*13.1mm
Features:
2.4 GHz wireless transceiver module
Build-in special PCB antenna and antenna connector, using flexible
Support FSK, GFSK, ASK/OOK and MSK
With programmable control output power,all supported frequency band can be reached to +23dBm
Flexible configuration of multi communication channels
Fast frequency switching characteristics can satisfy the need of Frequency hopping systems
Package Included:
1 x Module
