Caddx Firefly 1/3" CMOS 1200TVL 2.1mm Lens 16:9 / 4:3 NTSC/PAL FPV Camera With VTX For RC Drone - 24.00 €

Caddx Firefly 1/3" CMOS 1200TVL 2.1mm Lens 16:9 / 4:3 NTSC/PAL FPV Camera With VTX For RC Drone
Seller: Banggood,
Free shipping aviable, Registered postage from 25 €


Caddx Firefly 1/3" CMOS 1200TVL 2.1mm Lens 16:9 / 4:3 NTSC/PAL FPV Camera With VTX For RC Drone

Specifications of Camera:

Brand Name: Caddx
Item Name: Firefly
Color: Black
Lens: 2.1mm

Image Sensor:1/3" CMOS Sensor
Horizontal Resolution:1200 TVL
TV System:NTSC / PAL (optional)
Image:16:9 / 4:3 (optional)
Synchronization:Internal
Electronic ShutterPAL: 1/50~100,000; NTSC: 1/60~100,000
S/N Ratio:>52dB (AGC OFF)
Video Output: CVBS
Min. Illumination:[email protected]
Auto Gain Control:YES
BLC:YES
WDR:Global WDR
DNR:2 DNR
Dimensions:14mm*14mm*16mm
Wide Power Input:DC 3.3-9V
Work Temperature:-20℃~+60℃
Work Humidity:20%~80%
Weight:4.1g (Camera + VTX)

Specifications of VTX:

Feature:TBS SMART OSD
Frequency Band:5362~5945MHz
Channel Customer:48
Modulation Type:FM
Channel SEL.:Touch Switch
Channel Indicate:CH1~CH8 Channel indication with 8LEDS and A~F frequency group Indicate with 6 LEDS
Transmit Power:13±1dBm
Frequency Control:PLL
All Harmonic:Max -50dBm
Frequency Stability:±100KHz (Typ.)
Frequency Precision:±200KHz (Typ.)
Channel Carrier Error:1dB
Antenna Port:50 Ω
Power Consumption:140±20MA@5V DCIN
Supply Voltage:2.9-5.5V
Operating Temperature:-10℃~+60℃
Profile Dimension:15mmx14mm

Frequency Table:
BAND CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8
A (BOSCAM) 5865M 5845M 5825M 5805M 5785M 5765M 5745M 5725M
b (BOSCAM) 5733M 5752M 5771M 5790M 5809M 5828M 5847M 5866M
C (BOSCAM) 5705M 5685M 5665M 5645M 5885M 5905M 5925M 5945M
d (FATSHAR) 5740M 5760M 5780M 5800M 5820M 5840M 5860M 5880M
E (RACEBAN) 5658M 5695M 5732M 5769M 5806M 5843M 5880M 5917M
F 5362M 5399M 5436M 5473M 5510M 5547M 5584M 5621M
Note: Betaflight OSD configuration is not supported the F group channel at this time.

English Manual, Click Here

Package Included:

1x Caddx Firefly 1/3" CMOS 1200TVL 2.1mm Lens FPV Camera With VTX
