Boscam RC832 FPV 5.8G 48CH Wireless AV Receiver - 19.99 €

Boscam RC832 FPV 5.8G 48CH Wireless AV Receiver
Seller: Banggood,
Free shipping aviable, Registered postage from 25 €


Boscam RC832 FPV 5.8G 48CH Wireless AV Receiver












Specification:
Brand name :Boscam
Item name:RC832 48CH receiver

Sensitivity: ≤-90dBm
Working frequency: ISM 5.8GHz
Power supply: DC 12V
Consumption current: 200mA, Max.
Antenna input impedance: 500ohm Typ.
Antenna connector: SMA
Antenna gain: 2dBi
Video output level: 1.0Vp-p, Typ 75Ω
Audio output level: 1.0Vp-p, Typ 10kΩ
Audio carrier: 6.5MHz
Type standard: NTSC/PAL
Dimension: 80x65x15mm
Weight: 85g

Frequency Table Frequency Band A 5865 5845 5825 5805 5785 5765 5745 5725 Frequency Band B 5733 5752 5711 5790 5809 5828 5847 5866 Frequency Band E 5705 5685 5665 5645 5885 5905 5925 5945 Frequency Band F 5740 5760 5780 5800 5820 5840 5860 5880 Frequency Band R 5658 5695 5732 5769 5806 5843 5880 5917 Frequency Band L 5362 5399 5436 5473 5510 5547 5584 5621
Features:
48 channels
2 switching buttons
Digital display
Power off memory
Independent video and audio signal outputs

Package Included:
1 X RC832 AV receiver
1 X Antenna
2 X Cable
