BG150 Frame Kit + LittleBee 20A-S ESC BLHeli_S + Racerstar RS1806 2300KV Motor + Runcam Swift 600TVL PAL Camera + Eachine ET200R 200mW VTX + F3 6DOF Acro + 6 Pairs Gemfan 3035 Propeller
Items Description Features BG150 Frame Kit
Diagonal Wheelbase: 150mm
Main board thickness: 2mm
Other bord thickness: 1mm
Size: 145x145mm
Size: 145x145mm
Carbon weight: 58g
PDB: BEC 5/12V 3A
LED board: WS28128
3K high strength carbon board to ensure that the framework is strong.
Wheelbase 150mm, more suitable for a small range of space through.
Battery positions and motor pull plane at the same level, focus on the focus, so that the flight is more stable, more smooth rolling.
Flat plane, small wind resistance.
The structure is strong, beautiful, light weight (58g)
Lens adjustable, adjustable 45 degree.
The camera comes with fixed lens, CCD lens fixed for the market 95%.
The distribution of WS28128 LED 6 high brightness lamp plate, ensure flight stimulation (need to support flight control)
With a plate (PDB), BEC (5/12v 3A)
5.8G Wireless AV Transmitter installation modes, can be installed in the nose or tail.
LittleBee 20A-S ESC BLHeli_S ESC
Item name: FVT LittleBee 20A-S ESC
Input Voltage: 2-4S Lipo
BEC Output: No
Continue Current: 20A, Burst Current: 25A up to 10S
Size: 23.5*12mm
Weight: 4g(include Power and signal wire)
Support Damped mode, Oneshot125, Oneshot42 and Multshot
MOS: Both low and high side fets are Nfets
Switching speed is very fast, it has dedicated driver chip
BLHeli S Bootloader & Firmware
Racerstar RS1806 2300KV Motor
KV: 2300
Configuration: NP
Stator Diameter: 23mm
Shaft Diameter: M5
Motor Dimensions(Dia.*Len): Φ23×19.5mm
Weight (g): 22.5g
Voltage: 2-3S
No.of Cells(Lipo): 2-3S
Max Continuous current(A): 7.6A
Max Continuous Power(W): 84.4W
Internal resistance: â¦
Usage: for QAV250 ZMR250 260 Glass Multirotor Frame Kit
Low vibration motor great for flying
To make aircraft more stable
Less operating noise
More efficient
Bearings long life
Runcam Swift 600TVL PAL Camera
Color: Black
IR: IR Sensitive
Image Sensor: 1/3 SONY SUPER HAD II CCD
Horizontal Resolution: 600TVL
Lens: 2.8mm
Signal System: PAL
OSD SET: Yes
S/N Ratio: >60dB(AGC OFF)
Electronic Shutter Speed: PAL:1/50-100,000
Auto Gain Control(AGC): Yes
Back light compensation(BLC): Yes
Min.lllumination: 0.01LuX/1.2F
WDR: D-WDR
DNR: 2DNR
Day/Night: Auto/Color/B&W
Power: DC 5 to 17V
Dimension: 26mm x 26mm x 30mm
Weight: 12.6g Eachine ET200R 200mW VTX
Modulation : Broadband FM
Support Video Format : NTSC/PAL
Output Impedance : 75 Ohm
Output Signal : 23~24dBm
Output Power : 200mW
Wireless Channels : 40CH (with RaceBand)
Power Supply : 3S 11.1V
Working Voltage : 7V-24V
Output Voltage: 3.6-5.5V
Current :ã190mA
Audio Carrier : 6.5MHz
Antenna Connector : RP-SMA
Dimention : 38mm x 22.5mm x 6mm
Weight : 6g(without antenna) 15g (with antenna)
Frequency Table Frequency Band A 5865 5845 5825 5805 5785 5765 5745 5725 Frequency Band B 5733 5752 5711 5790 5809 5828 5847 5866 Frequency Band E 5705 5685 5665 5645 5885 5905 5925 5945 Frequency Band F 5740 5760 5780 5800 5820 5840 5860 5880 Frequency Band R 5658 5695 5732 5769 5806 5843 5880 5917 40 channels: Cover A,B,E,F,R bands
With voltage step-down function to 3.6V-5.5v , can work directly with 3S 11.1V battery. F3 6DOF Acro Flight Controller
Integrated OSD
36x36mm board with 30.5mm mounting holes
STM32F303 CPU, 72Mhz inc FPU
High-Capacity Flash (Acro and Deluxe)
MPU6050 accelerometer/gyro
2x 8pin JST-SH sockets (PPM, PWM, SERIAL RX, GPIO, ADC, 3V, 5V, GND)
1x 4pin JST-SH socket for SWD debugging
1x 5pin JST-SH socket for Flash firmware and Configuration (Connect to the CP2104 uart to usb tool)
8x 3pin though-holes for pin headers for ESC/Servo connections
4x 2pin though-holes for pin headers for 1x serial port and i2c port
8x 1pin though-holes for pin headers for battery voltage/buzzer/Video in/Video out
Gemfan 3035 3 Blade Propeller
Length: 3 inch
Pitch: 3.5 inch
Material: Poly Carbonate
Weight: 1.27g
Weight: 1.27g
Hub Id Dia: 5mm
Hub Od Dia: 12mm
Hub Thickness: 5.5mm
Adapter Rings: no
Quantity: 6 paris
Color: green, black and orange
Color: green, black and orange
Package included:
1 x BG150 Frame Kit
1 x PDB
4 x FVT LittleBee 20A-S ESC
2 x Racerstar RS1806 2300KV Brushless Motor CW
2 x Racerstar RS1806 2300KV Brushless Motor CCW
1 x Runcam Swift 600TVL PAL Camera
1 x Eachine ET200R Transmitter
1 x F3 6DOF Acro Flight Controller
2 x Gemfan 3035 3 Blade Propeller black CW
2 x Gemfan 3035 3 Blade Propeller black CCW
2 x Gemfan 3035 3 Blade Propeller green CW
2 x Gemfan 3035 3 Blade Propeller green CCW
2 x Gemfan 3035 3 Blade Propeller orange CW
2 x Gemfan 3035 3 Blade Propeller orange CCW
