BS-357B datasheet, please click here.
Specification:
Item name: Beitian BS-357B GPS antenna module
Dimensions: 35.0mm*27.0mm*8.0mm
Weight: 13.9g
Connector: 1.25mm 6pins connector
Built-in Flash, RS-232 level, 9600, 1Hz output, NMEA-0183 protocol output
Electrical Characteristics
Chipset: G7020-KT
Frequency: GPS L1, SBAS L1, QZSS L1Chipset: G7020-KT
Receiving Format: GPS, SBAS, QZSS
Channels: 56 Searching Channel
Sensitivity
Tracking: -162dBm
Reacquisition: -160dBm
Cold Start: -148dBm
Accuracy
Position Horizontal: 2.0 m (Typical Open Sky)
Velocity: 0.1m/sec 95% (SA off)
Timing: 1us synchronized to GPS time
Acquisition Time
Cold Start: 29s
Warm Start: 25s
Hot Start: 1s
Data Output
Support Rate: 4800bps to 921600bps, Default 9600bps
Data Level: USB, TTL or RS-232, Default RS-232 level
Data Protocol: NMEA-0183 or UBX, Default NMEA-0183
NMEA Message: RMC, VTG, GGA, GSA, GSV, GLL
Update Rate: 1Hz-10Hz, Default 1Hz
FLASH: 4M FLASH, Store the configuration permanently
Operational Limits
Altitude: 50,000m Max
Velocity: 515m/s Max
Acceleration: Less than 4g
Power Consumption
VCC: DC Voltage 3.6V-5.5V, Typical: 5.0V
Current: Capture [email protected]
Environment
Operating Temp: -40 °C ~ +85°C
Storage Temp: -40°C ~ +105°C
Built-in LED
TX LED: blue. The data output, TX LED flashing
PPS LED: red. PPS LED not bright when GPS not fixed, flashing when fixed
Package included:
1x Beitian BS-357B GPS antenna module
