BeeCore OMNIBUS F3 V1 Flight Controller Built-in OSD Integrated 5A Blheli_S DSHOT Brushless ESC
Specification:
Flight controller:
Firmware: betaflight_3.2.0_OMNIBUS
CPU: STM32F303CCT6 (72MHZ, 256K FLASH)
Sensor: MPU-6000 triaxial accelerometer / triaxial gyroscope (SPI connection)
Power supply: 1S battery input (DC 3.6-4.2V)
BEC: Built-in 5V / 0.5A step-up circuit
Compatible Receivers signal: PPM, SBUS, IBUS, Spektrum DSM2 / DSMX, 1024/2048.
Built-in OSD interface
Active buzzer interface (with buzzer)
Support BLheli suite ESC programming
Support DHSOT ESC
Built-in voltage detection, alarm
Board size: 28.5 * 28.5MM
Screw hole spacing: 36 * 36MM diameter 3.0MM
Board weight: 2.8 g
ESC:
Power supply: 1S
Current: 5A continuous peak 6A (3 seconds)
Support BLHeliSuite programmable
Factory firmware: O_L_5_REV16_6.HEX
Signal Support: D-shot150, D-shot300, D-shot600, Oneshot125, Multishot, PWM
Package Included:
1 X OMNIBUS F3 V1 Flight Controller Built-in OSD Integrated 5A Blheli_S DSHOT Brushless ESC
1 X Buzzer
1 X Power cable
