Introduction:
Pixconcise optimization of F4BY, Replace IMU & Compasser to InvenSense ICM20689 IMU, Ist8310 compass as Pixhawk4 Sensors.
Support for this board is available with Ardupilot Chibios Boards.
Specification:
Item Name: Autopilot PixConcise Flight Controller
Version: Bend Pins / Straight Pins ( Optional)
Bend Pins: Points at all pins are bend pins
Straight Pins: Points at 1 Straight Pin and 2 Bend Pin
Dimension: 53x53x16mm
Weight: 9.6g ( Only Flight Controller)
40.5g ( With CNC Case)
Features:
- Arduploit firmware, Missionplanner Ground Station
- Compatible Arduploit kinds of hardware ( RTK GPS, CAN etc.)
- Have innter extand IMU Port and support Second IMU Module Extend
- Support Max. 12 PWM Signal Output and full I/O port
- Support Dual GPS Module,
- using Dual External Compass Function, With CNC Case
- Application for RC Multi-Rotor, Airplane, Cars and Robot
Package Included:
1x Flight Controller
1x SH1.0 8p to SH1.25 8p power Module wire
1x SH1.0 4p to Dupon 2.54 4p OSD wire
1x SH1.0 4p to SH1.25 4p IIC wire
2x SH1.0 4p single plug GPS or Telemetry Module wires
1x 3pin Dupon 2.54 to Dupon receiver wire
1x IIC Splitter
1x Buzzer & 2pin Dupon 2.54 wire
1x 3M Double sided tape
1x 3D printing vibration dampening mount
