Description:
Item Name: 315 433 MHz transmitter and receiver
Receiver module parameters:
1.Product Model: MX-05V
2.Operating voltage: DC5V
3.Quiescent Current: 4mA
4.Receiving frequency: 315MHz / 433MHz
5.Receiver sensitivity:-105DB
6.Size: 30 x 14 x 7mm
Technical parameters of the transmitter head
1.Product Model: MX-FS-03V
2.Launch distance : 20-200 meters (different voltage, different results)
3.Operating voltage: 3.5-12V
4.Dimensions: 19 x 19mm
5.Operating mode: AM
6.Transfer rate: 4KB / S
7.Transmitting power: 10mW
8.Transmitting frequency: 315MHz / 433MHz
9.Pinout from left → right: (DATA; VCC; GND)
Package Included:
1 x Receiver module( 315MHZ / 433MHZz)
1 x Transmitter module ( 315MHz / 433MHz )
