PIX 2.43 Latest Version Flight Control 32 Strongest Open Source Flight Control STM32F4
Description:
Name:PIX 2.43 Flight Control
Type:STM32F4
Weight :38g
Width : 50mm
Length :81.5mm
Thickness :15.5mm
Processor:
1)32 STM32F427 Cortex M4,with hardware floating-point processing unit
2)Speeds:168MHZ, 256K RAM, 2M Flash
3)32 STM32F103 backup coprocessor
Sensor:
1) LSM303D 3 -axis accelerometer 14 / magnetometer
2)MPU6000 3 -axis gyroscope / accelerometer
3)L3GD20 3 -axis digital gyroscope 16
4)MS5611 precision barometer
Power Systems:
1)All peripherals have overcurrent protection, all input ESD protection
2)Ideal diode controller with automatic failover
3)servos and high current maximum 7V
Feature:
1)Multicolor LED lights.
2)High power, multi-tone buzzer.
3)Rich peripherals (UART, I2C, SPI, CAN).
4)External security button to easily start the motor.
5)Redundant power inputs and automatic failover.
6)Micro SD, prolonged high rate recorded flight data.
7)Backup System Integration mixing functions, providing automatic and manual mixing mode.
8)32-bit ARM CortexM4 advanced high-performance processor, you can run NuttX RTOS real-time operating system.
9)14 PWM / servo outputs (of which eight have security and manual control functions, in addition to six auxiliary, compatible with high power).
10)Redundant design, integrated backup power supply and basic safety flight controller, the master controller failure can be safely switched to a backup control.
Package include:
1 x PIX 2.43 Flight Control
