Aomway RX004 DVR 5.8GHz 32CH Video Receiver With Built In Video Recorder
The Aomway 5.8GHZ receiver with built in DVR is the perfect accessory for your FPV system! This micro SD DVR (Digital Video Recorder) allows you to easily record everything you see and hear from your FPV model's camera directly to a micro SD card. This eliminates the need for bringing your laptop or other DVR device to the field.
The Aomway DVR Receiver is nice and small in size for easy integration into your ground station, but big in quality and features. The receiver uses the same two button interface, one for the band and one for channel with a bright LCD, making channel swapping a breeze. There are two independent AV outputs for both audio and video, one is processed by the DVR for playback or blue-screen monitor, the other is DVR Bypassed for latency free video.
Use the DVR to record your flight, for when your significant other asks where you were for the last 4 hours. Powering the receiver at the field is as easy as plugging in a 2~6 cell lipoly into the included prewired cable. It just doesn’t get any simpler than this.
Description:
Brand: Aomway
Memory: Micro SD (Trans flash) up to 64GB (not included)
Working frequency: 5740-5880MHz (fatshark dedicated ) / 5705-5945MHz ( universal )/5733-5866MHZ/5725-5865MHZ
DVR: D1 format,one channel video recording
Video compression format: MJPG
Video output format: AVI
Video format: NTSC/PAL auto
AV video output: 2 AV output
High sensitive receive: >= -95%
Input voltage: DC 7-25V (2-6s)
Current consumption: 12V 170mA
Working frequency: 5.8G
Memory card: Max support 64GB. (also support memory card that less than 64GB, but not support one more than 64GB.)
Memory card: Max support 64GB. (also support memory card that less than 64GB, but not support one more than 64GB.)
15 transmit channels : CH-1 7channels CH-2 8channels
Sound: about two-channel stereo output
Weight : 126g
Size : 80 x 70 x 25mm
Features:
5.8G receiver, 32 frequency point, cover almost all frequency band.
Frequencyband and frequency point independant display, aovoid mistake.
Upgrade video circuit and sensitivity, with 1W telemetry, could fly 32KM.
Add DVR video recording function, perfect synchro.
Package included:
1 x 5.8G receiver with DVR Recorder
1 x Antenna
1 x AV male cable
1 x AV female cable
1 x Power cable
