AOMWAY 7 Inch LCD 5.8G 32CH Dual Receiver FPV Monitor DVR with Sunshade Built-in Battery
Description:
Brand Name: AOMWAY
Item Name: Monitor with Dual Receiver
Loudspeaker Power: 2W
Power Consumption: ≤5W
Input power: 8-26V
Battery: 2200mAh Lipo battery
DVR function: Yes
Video: Video input and output
Interface: DC IN, AV IN, AV OUT.
Dimension: 180*120*30mm
Weight: 870g
Display:
LCD size: 7 inch, no blue screen
Resolution: 1024*600
Record Resolution: D1,PAL 720*576
Imange scale: 16:9, 4:3 support image rollovers
View angle: 80/80 degree (L/R) 60/70 degree (U/D)
Brightness: 500cd/m2
Receiver:
Sensitive: -95dBm
Receiver: Dual receiver and auto search channel
Frequency: FR1 5705-5945MHZ/FR2 5733-5866MGZ/ FR3 5725-5865MHZ/ FR4 5740-5880MHZ
Band and Channel selection
CH CH 1 CH 2 CH 3 CH 4 CH 5 CH 6 CH 7 CH 8 GROUP A 5865 MHZ 5845 MHZ 5825 MHZ 5805 MHZ 5785 MHZ 5765 MHZ 5745 MHZ 5725 MHZ b 5733 MHZ 5752 MHZ 5771 MHZ 5790 MHZ 5809 MHZ 5828 MHZ 5847 MHZ 5866 MHZ C 5705 MHZ 5685 MHZ 5665 MHZ 5645 MHZ 5885 MHZ 5905 MHZ 5925 MHZ 5945 MHZ d 5740 MHZ 5760 MHZ 5780 MHZ 5800 MHZ 5820 MHZ 5840 MHZ 5860 MHZ 5880 MHZ
Band and Channel selection
CH CH 1 CH 2 CH 3 CH 4 CH 5 CH 6 CH 7 CH 8 GROUP A 5865 MHZ 5845 MHZ 5825 MHZ 5805 MHZ 5785 MHZ 5765 MHZ 5745 MHZ 5725 MHZ b 5733 MHZ 5752 MHZ 5771 MHZ 5790 MHZ 5809 MHZ 5828 MHZ 5847 MHZ 5866 MHZ C 5705 MHZ 5685 MHZ 5665 MHZ 5645 MHZ 5885 MHZ 5905 MHZ 5925 MHZ 5945 MHZ d 5740 MHZ 5760 MHZ 5780 MHZ 5800 MHZ 5820 MHZ 5840 MHZ 5860 MHZ 5880 MHZ
Package Included:
1 x Monitor
1 x Sunshade
2 x Antenna
3 x Cable
