Description:
Brand Name: Aomway
Item Name: 5.8G 500mW DVR TX RX Set
Transmitter Specifications:
Wide voltage input: DC7-16V
Consumption: 12V 220mA 15% fluctuate
Power: 500mW/26.5dBm
Dual frequency point: 5740-5860Mhz(Fatshark)/5705-5946Mhz(common)
15 transmite channel: CH-1 7/CH-2 8
Audio: Left/Right stereo
Format: PAL/NTSC
Output voltage: 5V-12V
Weight: 17g
Size: 5.5*2.7*0.7cm
Receiver Parameters:
Working Frequency: 5740-5860MHz (Fatshark dedicated ) / 5705-5945MHz ( Universal )
5733-5866MHZ/5725-5865MHZ
DVR: D1 format,one channel video recording
Wide input voltage : 7V-16V
DC 12V,170mA
15 transmit channels : CH-1 7channels CH-2 8channels
Sound: about two-channel stereo output
AV Video Output: 2 AV output
Weight : 126g
Size : 80 * 70 * 25mm
Features:
Transmitter Features:
Transmitter Features:
Upgrade video circuit and sensitivity, with 1W telemetry, could fly 32KM
Add DVR video recording function, perfect synchro
The lightest transmitter, only 17g
With 3.5dbi omni directional antenna, improve the AV transmission distance and quality
Receiver Features:
5.8G receiver, 32 frequency point, cover almost all frequency band
Frequencyband and frequency point independant display, aovoid mistake
Upgrade video circuit and sensitivity, with 1W telemetry, could fly 32KM
Add DVR video recording function, perfect synchro.
Package Included:
1 x 500mW Transmitter
1 x 5.8G RX004 Receiver with DVR Recorder
2 x 3db Antenna
2 x DC cable
3 x Video cable
